Bourns SRP5030CA-2R2M Power Inductor 2.2uH20% 9.7A
ManufacturerBourns(View more products from this manufacturer)
ModelSRP5030CA-2R2M
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 5.3 mm
Height: 2.9 mm
Length: 5.5 mm
Core Type: Wirewound
Shielding: Shielded
Tolerance: 20 %
Inductance: 2.2 uH
Application: Power
Termination: Standard
Unit Weight: 512 mg
Core Material: Ferrite
Qualification: AEC-Q200
Mounting Style: PCB Mount
Termination Style: SMD/SMT
Maximum DC Current: 7.2 A
Saturation Current: 10 A
Maximum DC Resistance: 14.5 mOhms
Self Resonant Frequency: 33 MHz
Maximum Operating Temperature: + 155 C
Minimum Operating Temperature: - 55 C
