Bourns SRP1245A-R56M Power Choke 0.56uH 20% SMD 1245 AEC-Q200
ManufacturerBourns(View more products from this manufacturer)
ModelSRP1245A-R56M
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 12.5 mm
Height: 4.8 mm
Length: 13.5 mm
Core Type: Wirewound
Q Minimum: 20
Shielding: Shielded
Tolerance: 20 %
Inductance: 560 nH
Application: Power
Termination: Standard
Unit Weight: 5.100 g
Core Material: Carbonyl Powder
Qualification: AEC-Q200
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 36 A
Saturation Current: 55 A
Maximum DC Resistance: 1.5 mOhms
Self Resonant Frequency: 60 MHz
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
