BKPRECISION HVL150250 Programmable DC Electronic Load (2000 W; 150 V / 250 A)

Max. Power: 2000 W

Voltage / Current Input Ratings: 150 V / 250 A

Features

Form Factor: 3U

Operating Modes: CC / CV / CR / CW

Max. CC Mode Accuracy: 0.05% + 0.05% F.S.

Minimum Operating Voltage: 1.5 V

Front Panel: USB host port for data logging and 4.3-inch display

Protection: OVP/OCP/OPP/OTP/OCL/OPL/Under voltage lockout, reverse voltage protection/oscillation detection

Additional Functions: List mode, transient mode, adjustable voltage/current slew rates, external analog control, parallel operation

General

Operating Software: Operating software and battery test software provided

I/O Interfaces: USB, LAN, RS232, and GPIB standard

Weight: 48.5 lbs (22 kg)

NRTL mark: cTUVus certification mark

Datasheet
