BKPRECISION 2567B-MSO Mixed Signal Oscilloscope (200MHz, 2GSa/s, 4 analog channels)

Performance Characteristics:

Bandwidth: 200 MHz

Rise Time: 1.7 ns

Input Channels: 4 analog channels + EXT; 16 digital channels for MSO

Sample Rate: 2 GSa/s (interleaving mode); 1 GSa/s (non-interleaving mode)

Vertical System:

Input Coupling: DC, AC, GND

Input Sensitivity:

1 MΩ: 500 µV/div to 10 V/div;

50 Ω: 500 µV/div to 1 V/div

Input Impedance: 1 MΩ ± 2% or 17 pF ± 2pF; 50 Ω: 50 Ω ± 1%

Max Input Voltage: 1 MΩ: ≤ 400 Vpk (DC + AC), DC to 10 kHz; 50 Ω: ≤ 5 Vrms, ± 10 Vpk

Horizontal System:

Time Base Range: 1 ns/div to 1000 s/div

Time Base Accuracy: ± 1 ppm; ± 1 ppm after first year; ± 3.5 ppm after 10 years

Display Characteristics:

Display: 10.1” TFT-LCD Capacitive touch screen

Resolution: 1024 x 600

Language: English, Spanish, Traditional and Simplified Chinese, French, Japanese, German, Russian, Italian, Portuguese

I/O:

Front Panel: USB 2.0 host x2, Probe compensation

Rear Panel:

USB 2.0 device, LAN: 100 Mbps

EXT trigger: EXT ≤ 1.5 Vrms, EXT/5 ≤ 7.5 Vrms

Aux Out: TRIG OUT 3.3 V LVCMOS; PASS/FAIL OUT 3.3 V TTL

General:

Dimensions (W x H x D): 13.9" x 8.8" x 4.4" (352 x 224 x 111 mm)

Weight: 8.6 lbs (3.9 kg)

Included Accessories: Four passive probes, power cord, USB Cable, Certificate of Calibration

Optional Accessories: Rack mount kit (RK2560B)
