Bird 1500-WA-MFN-10 Uni-Directional RF Attenuator (1.5kW, WA series, Male/Female, N, 10dB)
ManufacturerBird(View more products from this manufacturer)
Model1500-WA-MFN-10
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Power Rating: 1500 W
Connector: N
VSWR and Frequency Range:
1.10:1 DC ~ 1GHz
1.25:1 1 ~ 2.4 GHz
Coolant Method: Forced Air Cooled
Temperature: -40 ~ 40°C (-40 ~ 104 °F)
PIM: -110 dBc Min.
AC Power: 115/203V AC Inputs
Humidity: 95% non-condensing
Standard Attenuation Values: 10dB
Dimensions: 20.4 x 10.7 x 5.9” / 519 x 272 x 150mm
Weight: 30.0 lbs. / 13.6 kg
Finish: Black Anodized Aluminum
