Bettersize BetterPyc 380 Versatile Gas Pycnometer (10 - 65 ℃, 0.0001 g/cm³)

General

Measuring Principle: Gas Displacement Method

Measuring Parameters: Volume, Density

Cup Capacity: 10 cm³, 35 cm³, 100 cm³ (nominal)

Measurement Performance

Sample Volume: 1-100 cm³

Temperature Range: 10-65 ℃

Temperature Stability: 0.05 ℃

Transducer Accuracy: ≤ 0.1%

Accuracy: 0.03%

Repeatability: 0.01%

Resolution: 0.0001 g/cm³

Analysis Gas

Pressure Range: 0-22 psig (0-152 kPag)

Type: Helium/Nitrogen (suggested)

Instrument Dimensions

Weight: 10.6 kg

W × D × H: 345 mm × 297 mm × 221 mm

Supply Voltage: 100/240 V, 50/60 Hz

Software

System: Windows 7 or higher

Connections: USB ports
