Bel Power Solutions SLIN-12E1ALG Non-Isolated / PoL Non-Isolated DC-DC Converter 60W

Width: 11.43 mm (0.45 in)

Height: 8.5 mm (0.335 in)

Length: 20.32 mm (0.8 in)

Industry: Industrial

Unit Weight: 3.680 g

Output Power: 60 W

Mounting Style: SMD/SMT

Number of Outputs: 1 Output

Input Voltage - Max: 14 V

Input Voltage - Min: 4.5 V

Input Voltage, Nominal: 9 V

Output Current-Channel 1: 12 A

Output Voltage-Channel 1: 690 mV to 5.5 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
