Bel Power Solutions 70IMX7-05-05-8 Isolated DC-DC CONVERTER

Width: 25.4 mm (1 in)

Height: 10.5 mm (0.413 in)

Length: 50.8 mm (2 in)

Industry: Industrial

Output Power: 7 W

Input Voltage: 40 V to 121 V

Mounting Style: Through Hole

Number of Outputs: 2 Output

Input Voltage - Max: 121 V

Input Voltage - Min: 40 V

Output Current-Channel 1: 700 mA

Output Current-Channel 2: 700 mA

Output Voltage-Channel 1: 5 V

Output Voltage-Channel 2: 5 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
