Banner Engineering QS18EK6EVQ7 Photoelectric Sensors WORLD-BEAM QS18 Series: Visible Red Emitter; Range: 20 m; Input: 10-30 V dc; Output: Not Applicable; M8 Integral QD

IP Rating: IP65, IP67

Unit Weight: 49.895 g

Light Source: Visible Red LED

Amplifier Type: Photoelectric

Sensing Method: Opposed Emitter

Sensing Distance: 1 m to 20 m, 0 m to 4 m

Connection Method: 4-Pin M8 Pico

Output Configuration: NPN, PNP

Supply Voltage - Max: 30 VDC

Supply Voltage - Min: 10 VDC

Operating Supply Voltage: 10 VDC to 30 VDC

Maximum Operating Temperature: + 70 C

Minimum Operating Temperature: - 20 C
