Banner Engineering PSDINP-24-06 DIN Rail Power Supplies DC Power Supply Din Rail Mount C1D2; Input 100-240 V ac 50/60 Hz; Output 24-28 V dc 0.6 A 15 W; Terminal Block Connectors

Width: 22.5 mm (0.886 in)

Height: 75 mm (2.953 in)

Length: 91 mm (3.583 in)

Industry: Industrial

Dimensions: 91 mm x 22.5 mm x 75 mm

Input Type: 1-Phase / Single Phase

Unit Weight: 99.790 g

Output Power: 15 W

Input Voltage: 100 VAC to 240 VAC, 110 VDC to 300 VDC

Mounting Style: DIN Rail Mount

Number of Outputs: 1 Output

Open Frame/Enclosed: Enclosed

Output Current-Channel 1: 630 mA

Output Voltage-Channel 1: 24 VDC to 28 VDC

Maximum Operating Temperature: + 70 C

Minimum Operating Temperature: - 10 C
