Features
Measuring range: 10KPa-2MPa
Working Temperature: -25 to +95C
Current Output: 4 – 20 mA 2 wires Hart Protocol
Power Supply: 24VDC
Ambient Temperature: -25 to +120C
Process connection: DN50PN16, DN80PN16, as required
Extented diaphragm diameter:50mm,100mm,150mm,as required
Electrical Connections: 1/2”NPT or M20*1.5
Enclosure:IP65
Intrinsically Safe: ia II C T6
Explosion proof: d II B T5
Diaphragm material: SUS316L, Hastelloy C,Tantalum
Industrial application
Process control system
Petroleum industry
Chemical industry
Power plant
