Sensitivity: 7~11 mV/g, 9mV/g (typ)
Lower Frequency Limit(±3 dB limit):2(typ), 5 (max) Hz
Upper Frequency Limit(±3 dB limit): 10 (min), 20(typ) kHz
Dynamic Range: ±150g
Linearity: 1.0 %
Transverse Sensitivity: 2.0(typ), 5(max) %
Resonant Frequency: 35kHz
Supply Voltage: 3~40 Volts
Operating Temperature: -40~85 °C
Output Impedance: 20kΩ
Maximum Shock Level: 1000g
Weight ( Includes 40" cable and connector) Cable: 8grams
