ATTEN TPR6005T High Power CC/CV Linear Power Supply (5A, 30V, 300W)

Rated output power: 300W

Rated output voltage: 0-30V

Rated output current: 0-5A

Power supply voltage: 230VAC/115VAC(Optional)

Voltage

Power supply effect: ≤0.005%+1 mv

Voltmeter display precision: ±(0.1%+2digits)

Display resolution: 10mv

Load effect: ≤10mv

Voltage ripple: 0.8mV(rms)

Current

Power supply effect: ≤1mA

Voltmeter display precision: ±(0.2%+2digits)

display resolution: l mA

Load effect: ≤2mA

current ripple:≤4mA(rms)

Protection functions: ovP/OCP/OHP Protection

Heat-diss-pating method: lntelligent speed regulation air cooling

N.W: 11KG

Size(W*H*D): 270*178*350(mm)
