Artesyn ERM03C110-HS Isolated 50W 66-160Vin 15V 3.33A w/ Heatsink

Width: 36.8 mm (1.449 in)

Height: 12.7 mm (0.5 in)

Length: 57.9 mm (2.28 in)

Efficiency: 92 %

Output Power: 50 W

Input Voltage: 66 V to 160 V

Mounting Style: Through Hole

Mechanical Style: Isolated

Isolation Voltage: 3 kV

Number of Outputs: 1 Output

Input Voltage - Max: 160 V

Input Voltage - Min: 66 V

Input Voltage, Nominal: 110 V

Output Current-Channel 1: 3.33 A

Output Voltage-Channel 1: 15 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
