Artesyn CSU2000AP-3-100 Front-end Power Supply (12.2V/163.9A; 12V/3.5A; 2000W)

Input Range and Output Power: 90-127 Vac: 1400W; 180-264 Vac: 2000W

Frequency: 47 Hz to 63 Hz

Max input current: 100/200Vac: C14 14.4A/10A

Main DC Output

Nominal setting: MIN: -0.20%/NOM: 12/ MAX: 0.20%

Total output regulation range: MIN: -5%/ MAX: +5%

Output current: MIN: 1.0 A/ MAX: 163.9

Standby DC Output

Nominal setting: MIN: -3.5%/ NOM: 12.0/ MAX: +3.5%

Total output regulation range: MIN: -5%/ MAX: +5%

Output current: MIN: 0.1 A/ MAX: 3.5 A

Operating temperature: CSU1800AP-3-100/CSU2000AP-3 100/CSU2000AP-3-200: -5 to 55°C full rated power. Allowable up to TBD °C for short term operation

Operating relative humidity +5% to 95%, non-condensing

Descrption: 1U x 73.5 x 185mm 2000W, Platinum efficiency, red, C14

Outputs: 12.2V/163.9A ; 12.0V/3.5A

Airflow Direction: Forward

Datasheet
