Artesyn AVO50-48S2V5-4 Eighth-Brick Isolated DC-DC Converter (2.5V; 20A; 50W)

Input range: 36 - 75 Vdc

Efficiency: 91% @ 3.3 V, 5 V and 12 V

Maximum power: +/-1% to +/-1.6%

Line regulation: 5 V: 4 mV; 12 V: 9 mV; Others: 1 mV

Load regulation: 5 V and 12 V: 5 mV; Others: 1 mV

Noise/ripple:

- 1.2 V, 2.5 V, 3.3 V: 50 mV;

- 1.5 V, 5 V, 12 V: 55 mV;

- 1.8 V: 45 mV

I/O isolation: 1500 Vdc min.

Output voltage: 2.5 V @ 20 A

Power: 50W

Operating ambient temperature range: -40 °C to +85 °C

Storage temperature: -55 °C to +125 °C

Humidity: 5% to 95% (non-condensing)

Datasheet
