Artesyn AVO200-48S05B-6L Eighth-Brick Isolated DC-DC Converter (5V; 40A; 200W)

Input voltag:e 36 - 75 Vdc

Efficiency: 12 V at 100% load is 94%; 5 V at 100% load is 94.5%

I/O isolation: 2250 Vdc

Output Voltage: 12 V nominal; 5 V nominal

Output current maximum: 16.7 A for 12 V version; 40 A for 5 V version

Noise & ripple: 12 V is 70 mV pk-pk max; 5 V is 120 mV pk-pk max

200 W continuous power

Output voltage set point: 5 V / 40 A

Output current: 40 A

Efficiency: 94.5%

Operating temperature: -40 to +85°C

Storage temperature: -55 to +125°C

Datasheet
