Artesyn AEE03B18-LHS Isolated 40W 9 - 36Vin Single 12V@3.33A

Width: 31 mm (1.22 in)

Height: 17.2 mm (0.677 in)

Length: 50.8 mm (2 in)

Industry: Industrial

Efficiency: 90 %

Output Power: 40 W

Input Voltage: 9 V to 36 V

Mounting Style: Through Hole

Mechanical Style: Isolated

Isolation Voltage: 1.5 kV

Number of Outputs: 1 Output

Input Voltage - Max: 36 V

Input Voltage - Min: 9 V

Input Voltage, Nominal: 24 V

Output Current-Channel 1: 3.33 A

Output Voltage-Channel 1: 12 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
