AP&T AP-DY6702 Integrated Power Supply (AC175-240V)

Integrated Power Supply

Input voltage: AC175-240V

Output voltage: DC24V

Output current: 12.5A

Output Power: 300W

Product Size: 380*160*50

Work instructions: LED

Input indication: Digital display 0.28 Inch LED, monochrome

Product network port: 32 Port: P1-P32

Network port definition:

- 1, 2: White-orange, orange: VCC

- 3: White- blue: RS485_B

- 4: blue: RS485_A

- 5, 6, 9: White-green, green: GND, PE

- 7: White-brown: NPN-C1

- 8: brown: NPN-C2

Communication network port: DC \ PLC \ RS485 \ WAN/LAN

Illuminated switch: 16 Road：SW1-SW16

Working environment: temperature：0-50℃；humidity：30-70%

Net weight: 2500g

Gross weight: 2950g
