Anton Paar Litesizer DIA 100 Dynamic Image Analyzer (10 μm ~ 2,500 μm; 10 μm ~ 5,000 μm; 10 μm ~ 16,000 μm)

Measurement Principle: Dynamic Image Analysis

Measurement Ranges (Liquid Flow): 10 μm to 2,500 μm

Measurement Ranges (Dry Jet): 10 μm to 5,000 μm

Measurement Ranges (Free Fall): 10 μm to 16,000 μm (restrictions apply for particles >8,000 μm)

Camera: 5 Mpix (2,448 pixels x 2,048 pixels) / 10 μm per pixel

Data Collection Rate : 20 fps/camera at 5 Mpix

Magnification: 0.3x

Data Transfer: 1x 10 Gigabit Ethernet, 1x USB-A 3.0

Instrument Data:

Dimensions: 400 mm x 790 mm x 290 mm (H x W x D)

Weight: 41 kg (90 lb)

Power supply: 100 V to 240 V ±10 %, 50/60 Hz

Compressed air supply: 5 bar - 10 bar (72 psi to 145 psi)

Water supply: max. 8 bar (116 psi)
