Anton Paar DMA 6002 Sound Velocity Density And Sound Velocity Meter (0.000001 g/cm³; 0.1 m/s; 0.001 °C)

Measuring range

Density: 0 g/cm³ to 3 g/cm³

Sound Velocity: 1,000 m/s to 2,000 m/s

Temperature: 0 °C to 100 °C (32 °F to 212 °F)

Pressure: 0 bar to 8 bar (0 psi to 116 psi)

Accuracy*

Density: 0.000005 g/cm³

Temperature: 0.01 °C (0.02 °F)

Repeatability s.d.**

Density: 0.000001 g/cm³

Sound Velocity: 0.1 m/s

Temperature: 0.001 °C (0.002 °F)

Reproducibility s.d.**

Density: 0.000005 g/cm³

Sound Velocity: 0.5 m/s

Digital resolution

Density: 0.000001 g/cm³

Sound Velocity: 0.01 m/s

Dimensions (L x W x H): 526 mm x 347 mm x 230 mm (20.7 in x 13.7 in x 9 in)

Weight: 22.62 kg (49.87 lbs)

Power supply: AC 100 to 240 V, 50/60 Hz, fluctuation ± 10 %, 190 VA

Display: 10.1" TFT WXGA (1280 x 800 px); PCAP touchscreen

Controls: Touchscreen, optional keyboard, mouse, and barcode reader

Communication interfaces: 4 x USB, Ethernet, CAN, RS232

Internal storage: 10,000 measuring values including camera images

* According to ISO 5725

** Under ideal conditions and for low viscosities
