Analog Devices MAX77751CEFG+ Charge Management 14V Input, 3A USB Type C Autonomous Char

Features: Complete Li-Ion/Li-Polymer Switching Charger, Die Temperature Monitor with Thermal Foldback Loop (130 C Threshold), Integrated USB Detection, No External MOSFET Required, No Firmware / Communication Required, Reverse Boot Capability upto 5.1 V, 1.5 A, Short Circuit Protection, Smart Power Selector, 6-Hour Charge Safety Timer

Battery Type: Lithium-ion, Lithium Polymer

Mounting Style: SMD/SMT

Output Current: 3.15 A

Output Voltage: 4.5 V

Development Kit: MAX77751CEVKIT, MAX77751FEVKIT

Operating Supply Current: 3 A

Operating Supply Voltage: 4.5 V to 13.7 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
