Analog Devices MAX25601AATJ/VY+ Boost-Buck Controller Synchronous Boost with Synchronous Buck

Dimming: Analog, Dimming

Features: PWM Dimming, Short Circuit and Thermal Protection

Topology: Boost, Buck

Output Type: Open Drain

Input Voltage: 4.5 V to 36 V

Mounting Style: SMD/SMT

Output Current: 30 A

Output Voltage: 4.9 V to 5.1 V

Development Kit: MAX25601EVKIT#

Number of Outputs: 1 Output

Number of Channels: 1 Channel

Input Voltage - Max: 36 V

Input Voltage - Min: 4.5 V

Operating Frequency: 200 kHz to 2.2 MHz

Supply Current - Max: 10 mA

Pd - Power Dissipation: 2.759 W

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
