Analog Devices LTM8058IY#PBF Isolated uModule DC/DC Converter with LDO Post Regulator 3.1Vin to 31Vin Iso uModule DC/DC Conv

Shutdown: Shutdown

Topology: Flyback

Unit Weight: 1.128 g

Input Voltage: 3.1 V to 31 V

Mounting Style: SMD/SMT

Output Current: 440 mA

Output Voltage: 2.5 V to 13 V, 1.2 V to 12 V

Development Kit: DC1988A

Load Regulation: 1.5 %, 2 mV

Number of Outputs: 2 Output

Quiescent Current: 850 uA

Moisture Sensitive: Yes

Input Voltage - Max: 31 V

Input Voltage - Min: 3.1 V

Switching Frequency: Adjustable

Operating Supply Current: 850 uA

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
