Analog Devices LTC3886IUKG#TRPBF Step-Down Controller 60V 2x Out Buck Cntr w/ Dig Pwr S M

Shutdown: Shutdown

Topology: Buck

Fall Time: 30 ns

Isolation: Isolated

Rise Time: 30 ns

Mounting Style: SMD/SMT

Output Current: 15 A

Output Voltage: 500 mV to 13.8 V

Development Kit: DC2155A-A, DC2277A, DC2155A-B, DC2578A

Number of Outputs: 1 Output

Switching Frequency: 100 kHz to 750 kHz

Operating Supply Current: 26 mA

Operating Supply Voltage: 4.5 V to 60 V

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
