Core: Blackfin
MMACS: 2400 MMACS
Width: 17 mm
Height: 1.16 mm (Min)
Length: 17 mm
I/O Voltage: 2.5 V, 3.3 V
Unit Weight: 2.784 g
Data RAM Size: 4 kB
Data Bus Width: 32 bit
Interface Type: Parallell, SPI, UART
Mounting Style: SMD/SMT
Number of Cores: 2 Core
Watchdog Timers: Watchdog Timer
Instruction Type: Fixed Point
Processor Series: Blackfin
Moisture Sensitive: Yes
Program Memory Size: 328 kB
L1 Cache Data Memory: 2 x 32 kB
Supply Voltage - Max: 1.375 V
Supply Voltage - Min: 800 mV
Maximum Clock Frequency: 500 MHz
Operating Supply Voltage: 1.25 V
Number of Timers/Counters: 14 Timer
L1 Cache Instruction Memory: 2 x 16 kB
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
