Analog Devices ADSP-BF561SBBZ500 DSPs BKFN PROCESSOR,500MHz 1.25V

Core: Blackfin

MMACS: 2400 MMACS

Width: 27 mm

Height: 1.63 mm (Min)

Length: 27 mm

I/O Voltage: 2.5 V, 3.3 V

Unit Weight: 5 g

Data RAM Size: 4 kB

Data Bus Width: 32 bit

Interface Type: Parallell, SPI, UART

Mounting Style: SMD/SMT

Number of Cores: 2 Core

Watchdog Timers: Watchdog Timer

Instruction Type: Fixed Point

Processor Series: Blackfin

Moisture Sensitive: Yes

L1 Cache Data Memory: 2 x 32 kB

Supply Voltage - Max: 1.375 V

Supply Voltage - Min: 800 mV

Maximum Clock Frequency: 500 MHz

Operating Supply Voltage: 1.25 V

Number of Timers/Counters: 14 Timer

L1 Cache Instruction Memory: 2 x 16 kB

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
