Analog Devices ADPD4200BCBZR7 Multimodal Sensor Front End Simplified PPG from Coolidge

Resolution: 32 bit

Input Voltage: 1.7 V to 1.9 V

Sampling Rate: 9 kS/s

Interface Type: SPI

Mounting Style: SMD/SMT

Reference Type: Internal

Development Kit: EVAL-ADPD4200Z-PPG

Reference Voltage: 1.265 V

Number of Channels: 2 Channel

Number of Converters: 1 Converter

Supply Voltage - Max: 1.9 V

Supply Voltage - Min: 1.7 V

Analog Supply Voltage: 1.7 V to 1.9 V

Digital Supply Voltage: 1.7 V to 3.6 V

SNR - Signal to Noise Ratio: 105 dB

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
