Analog Devices ADAU1850BCBZRL Audio CODEC, Low Power 28-Bump Wafer Level Chip Scale Package

Resolution: 24 bit

Interface Type: I2C, SPI, UART

Mounting Style: SMD/SMT

Number of ADCs: 3 ADC

Number of DACs: 1 DAC

THD plus Noise: - 78 dBFS, - 95 dBFS, - 96 dBFS, - 96 dBV

Conversion Rate: 768 kHz

Development Kit: EVAL-ADAU1850EBZ

Supply Voltage - Max: 1.8 V, 3.63 V

Supply Voltage - Min: 1.62 V

Operating Supply Voltage: 1.8 V, 1.62 V to 3.63 V

SNR - Signal to Noise Ratio: 101 dB, 102 dB, 104 dB, 106 dB, 110 dB

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
