Analog Devices ADAQ8092BBCZ High Speed ADC DUAL-Ch 105MSPS DAQ uModule

Shutdown: Shutdown

Gain Error: 6 % FS

Resolution: 14 bit

Output Type: CMOS, LVDS

Interface Type: Serial

Mounting Style: SMD/SMT

Number of ADCs: 2 ADC

Reference Voltage: 1.25 V

Number of Channels: 2 Channel

Number of Converters: 2 Channel

Supply Voltage - Max: 1.9 V

Supply Voltage - Min: 1.7 V

Number of ADC Channels: 2 Channel

Pd - Power Dissipation: 394 mW

INL - Integral Nonlinearity: 1.7 LSB

SNR - Signal to Noise Ratio: 60.5 dB

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C

DNL - Differential Nonlinearity: 0.3 LSB
