Analog Devices AD676TD/883B S/H ADC IC, 16-BIT SAMPLING ADC
ManufacturerAnalog Devices(View more products from this manufacturer)
ModelAD676TD/883B
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 15.49 mm
Height: 5.34 mm
Length: 37.85 mm
Input Type: Single-Ended
Resolution: 16 bit
Architecture: SAR
Input Voltage: +/- 10 V
Sampling Rate: 100 kS/s
Interface Type: Parallel
Mounting Style: Through Hole
Reference Type: External
Sample and Hold: Yes
Number of Channels: 1 Channel
Number of ADC Inputs: 1 Input
Number of Converters: 1 Converter
Pd - Power Dissipation: 480 mW
INL - Integral Nonlinearity: 1 LSB
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
