Analog Devices AD4683BCPZ-RL7 Sampling SAR ADC 16-bit 500kSPS Pseudo Differential Dual

Shutdown: Shutdown

Gain Error: 0.02 %FS

Input Type: Pseudo-Differential

Resolution: 16 bit

Architecture: SAR

Sampling Rate: 500 kS/s

Interface Type: Serial

Mounting Style: SMD/SMT

Reference Type: External, Supply

Development Kit: EVAL-AD7383FMCZ

Reference Voltage: 3.3 V

Moisture Sensitive: Yes

Number of Channels: 2 Channel

Number of Converters: 2 Converter

Analog Supply Voltage: 3 V to 3.6 V

Pd - Power Dissipation: 17.2 mW

FPBW - Full Power Bandwidth: 25 MHz

INL - Integral Nonlinearity: 1 LSB

SNR - Signal to Noise Ratio: 87.5 dB

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C

DNL - Differential Nonlinearity: 0.5 LSB

THD - Total Harmonic Distortion: - 100 dB

SFDR - Spurious Free Dynamic Range: 101 dB

SINAD - Signal to Noise and Distortion Ratio: 87 dB
