AMPTEC RESEARCH 620LK-HR High Resolution Bonding Ohmmeter (20 mΩ, 200 mΩ, High resolution)

Range: 20 mΩ

Nominal Current: 1 A

Resolution: .001 mΩ

Accuracy: ± .025% of range

Range: 200 mΩ

Nominal Current: 100 mA

Resolution: .01 mΩ

Accuracy: ± .025% of range

Range: 2 Ω

Nominal Current: 100 mA

Resolution: .1 mΩ

Accuracy: ± .025% of range

Range: 20 Ω

Nominal Current: 10 mA

Resolution: 1 mΩ

Accuracy: ± .025% of range

Terminal: Trident

Display: 4 1/2 digit LCD

Update:1 reading per 3 seconds

Power: Internal rechargeable battery pack

Weight: 3 lbs.

Dimensions: 7.69″ x 7.56″ x 3″

Max. Internal Voltage: 5 VDC

Open Circuit: ~5 VDC

Operating Temperature Range: -20° to 50° C

Storage Temperature Range: -40° to 75° C

Temperature Coefficient: ± .0025% per 1° C

Max. Input Voltage: 250 VDC
