Amittari HAG-2000 Fog Film Gloss Meter (0~2000 GU; 20°, 60° , 85°)

Photometric Units: GU

Measuring Range: 0~2000 GU

Accuracy: ±1.5 (relative to the reference standard of JJG 696-2002)

Resolution: 0.1GU, repeatability:±0.5GU, error of indication: less than ±1.2GU

Projection Angle: 20°, 60° and 85°

Fog Shadow Units: HU resolution± 0. 1 HU, repeatability ± 0. 2 HU,±1.5 HU reproducibility

The Measurement Area: 7 x 14mm (ellipse)

Numerical Memory: 56 groups

Environment Temperature: 0°C~40°C

Relative Humidity: No more than 85%

Power Supply: 2x1.5V AAA (UM-4)

Size: 140mm x 45mm x 75mm

Weight: ±310g (Including Batteries)
