Amittari AR-132CT Concrete Surface Texture Meter (Ra/Rq: 0.005~20μm; Rz/Rt: 0.020~200μm)

Display: LCD

Parameters: Ra, Rz, Rq, Rt

Measurement Range:

Ra: 0.005~20μm

Rq: 0.005~20μm

Rz: 0.020~200μm

Rt: 0.020~200μm

Accuracy: Not more than ±10%

Fluctuation of Display: Not more than 6%

Resolution:

0.001μm if reading < 10μm

0.01μm if 10μm ≤ reading < 100μm

0.1μm if reading ≥ 100μm

Evaluation Length: 1~5L Optional

Operation Temperature: 0~50°C (32~122°F)

Operation Humidity: <80%RH

Power Supply: Lithium Ion Battery (Rechargeable)

Size: 140×57×48mm (5.5 × 2.2 × 1.9")

Weight (Including Battery): 420g (14.82oz)

Sensor:

Probe Angle: 90°

Radius: 10μm

Force: 16mN (1.6gf)

Material: Diamond

Principle: Inductance Type

Vertical Radius of Guiding Head: 48mm

Max. Driving Stroke: 17.5mm / 0.7inch

Cutoff Length: 0.25mm / 0.8mm / 2.5mm

Driving Speed:

Sampling:

When Sampling Length = 0.25mm, Vt = 0.135mm/s

When Sampling Length = 0.8mm, Vt = 0.5mm/s

When Sampling Length = 2.5mm, Vt = 1mm/s

Returning: Vt = 1mm/s

Accessories (EN):

Standard Accessories:

Main Unit

Standard Sensor

Standard Sample Plate

Adjustable Leg

Sheath of Sensor

Screwdriver

Power Adapter

Operation Manual

Carrying Case

Optional Accessories:

Groove Stylus

Curvature Probe

Small Hole Probe

Extension Rod

Measurement Stand

USB Cable & Software

Bluetooth Adapter & Software
