Amittari AMR-1004 Surface Roughness Test Stand (154×240×467mm, 500N)

Dimensions: 154×240×467mm (6.1×9.4×18.4")

Rated Load: 500N

Distance: 150mm (5.9")

Measurements & Applications

Standard Sensor: When measuring circular workpiece less than 20cm in diameter, easily rolling, unable to fix instrument to measure, it is necessary to use measurement stand.

Deep Groove Sensor: If the roughness of deep groove workpiece, or pedestal seat less than 10mm in height is needed to be measured, it is necessary to use the deep groove sensor with measurement stand.

Curvature Sensor: When the surface of workpiece is curved, cambered, or uneven. Only curvature sensor can be used to measure the surface roughness with test stand.
