Amittari AC-115S Color Meter (L*: 5 ~ 100)

Display: Triple 4 digit LCD Display

Auto power off: Approx. 3 minutes

Data memory capacity: 99 set. (Direct reading from LCD display)

Low battery indication:

Temperature: Operating: 0~40°C(32~104°F), Storage: -10~40°C(14~104°F)

Humidity: Operating: <85%RH., Storage: <70%RH.

Power source: 4x1.5 AAA (UM-4) Battery

Dimensions: Main unit: 140x70x31mm; Sensor : Φ44x55mm

Weight: 205g (not including battery)

Illuminating/ Viewing geometry: 45°/ 0°: Illumination at 45°, measrement at 0°

Illuminant: White LED lamp

Measuring area: Approx. Φ10mm

Display modes: Color difference: ∆(L*, a*, b*), ∆(E*ab, C*ab, H*ab), ∆(Y, x, y), ∆(X, Y, Z), ∆(Rs, Gs, Bs) or ∆(WI, YI, Tw)

Operating Temperature: Color space: (L*, a*, b*), (L*, C*ab, hab), (Y, x, y), (X, Y, Z), (Rs, Gs, Bs) or (WI, YI, Tw)

Target color memory: 9 channel; set by measurement or keypad

Measuring range: L*: 5 to 100

Measurement conditions: Observe: CIE 2° Standard Observer

RepeatabilIty: Standard deviation within ∆E*ab 0.5 (Measurement conditions: Average of measurements of standard white plate)

Measurements interval minimum: Approx. 2 seconds

Product Accessories

Standard Accessories:

Main Unit

Measuring head

White calibration card

Carrying Case

Operation Manual

Optional Accessories:

USB data output
