Alluris FMI-B30A5 Digital force gauge (5N)

Capacity F(nom) (N): 5

Resolution (N): 0.001

Accuracy (%): 0.15

Temperature coefficient (%/K ): 0.02

Reproducibility( % F(nom) ): 0.03

Repeatability (% F): 0.03

Hysteresis (% F): 0.075

Creeping (5min) (% F): 0.1

Measuring principle : Bidirectional force sensor with strain gauges and high-speed ?-processor

Nominal deflection( mm): 0.17

Measuring shaft : M6

Max. operating force (% F(nom)): 120

Breaking force (% F(nom)): 500

Display:

Type : 5-digit LCD | 12mm | Autoreverse

Refresh time (ms):  100 ... 1000

Operation modes:

Regular : N | kg | lb

Peak (real-time) : Display of peak value | Peak value of pull- or push force (drag indicator function)

Limits + Statistics : 2 separately adjustable limits | Single value memory and continuous measured value memory

Interface:

USB : USB 2.0 data communication

Hirose : Limit / overload signals. digital I/O's (1 input / 3 outputs). trigger. supply (optional data cable required)

Sensor : without

Power supply Type:  internal LiPo battery | operation time 150h

Temperature (operation) °C:  0 ... 40

Protection code (EN 60529) Cable not plugged:  IP40

Housing:

Material : Aluminium die cast

LxWxH (mm) : 150 x 82 x 29

Weight (kg) : 0.48

Mounting : 2xM4. 2xM5. adjusting holes D5(H7)

Datasheet
