Alif Semiconductor AE512F80F5582LS-T ARM Microcontrollers - MCU E5 fusion processor with 1x Cortex-A32, 2x Cortex M-55, 2x Ethos U-55, 5.5MB MRAM, 8.25MB SRAM, max peripherals, FBGA194

Core: ARM Cortex A32, ARM Cortex M55, Ethos-U55

I/O Voltage: 1.8 V, 3.3 V

Unit Weight: 240 mg

Data RAM Size: 5.5 MB, 8.25 MB

Data RAM Type: MRAM, SRAM

ADC Resolution: 3 x 12 bit, 24 bit

DAC Resolution: 2 x 12 bit

Data Bus Width: 32 bit/16 bit

Interface Type: CAN FD, Ethernet, I2C, I2S, I3C, MIPI-CSI, MIPI-DSI, SDIO, SPI, UART, USB 2.0

Mounting Style: SMD/SMT

Number of I/Os: 120 I/O

Watchdog Timers: Watchdog Timer

Moisture Sensitive: Yes

Program Memory Size: 0 B

Supply Voltage - Max: 4.2 V

Supply Voltage - Min: 1.75 V

Analog Supply Voltage: 1.8 V

Number of ADC Channels: 4 Channel, 18 Channel

Maximum Clock Frequency: 160 MHz, 400 MHz, 800 MHz

Number of Timers/Counters: 5 Counter, 16 Timer

Maximum Operating Temperature: + 75 C

Minimum Operating Temperature: - 40 C
