Alcoswitch - TE Connectivity 5569255-1 Modular 2X2 8/8 R/A LPRO

Color: Black

Gender: Jack (Female)

Shielding: Shielded

USOC Codes: RJ45

Application: 10/100 Base-T

Unit Weight: 30 g

Configuration: 2x2

Tab Direction: Tab Up and Tab Down

Current Rating: 200 mA, 1.5 A

Mounting Angle: Right Angle

Mounting Style: Through Hole

Number of Rows: 2 Row

Voltage Rating: 150 V

Contact Plating: Gold

Number of Ports: 4 Port

Contact Material: Phosphor Bronze

Termination Style: Solder

Flammability Rating: UL 94 V-0

Number of Positions: 8 Position

Performance Category: Cat 5

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

Number of Positions / Contacts per Port: 8P8C
