Aikoh UP-05K Low-Capacity Load Cell For Tensile & Compression Tests (5N)
ManufacturerAikoh(View more products from this manufacturer)
ModelUP-05K
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Rated capacity: 5N
Rated output: 1.0～1.5mV/V
Nonlinearity: 0.2％R.O.
Hysteresis: 0.2％R.O.
Repeatability: 0.1％R.O.
Recommended applied voltage: 6V
Allowable applied voltage: 10V
Input/output resistance: 350Ω±2％
Temperature compensation range: -10～+70℃
Allowable temperature range: -20～+80℃
Zero point influence by temperature: ±0.01％R.O./℃
Output influence by temperature: ±0.01％R.O./℃
Allowable overload: 150%R.C. (stopper provided on 5N type)
Cable length: 2m
Tip shape: 7P connector
