Gauge Pressure (R) (Zero At Atmospheric Pressure): 100 – 250 – 500 mbar; 1 - 2.5 - 5 - 10 - 20 bar
Absolute Pressure (A) (Zero At Absolute Vacuum Pressure): 1 – 2.5 – 5 – 10 – 20 bar; 50 - 100 – 250 - 350 - 500 - 700 bar; *1000-*1500-*2000 bar
Linearity And Hysteresis : ≤ ± 0.10 %
Temperature Effect (1°C):
a) on zero: ≤ ± 0.005%
b) on sensitivity: ≤ ± 0.005%
Nominal Sensitivity : 4-20mA (2 or 3 wires): 0-5 V, 0-10 V
Calibration Tolerance : ≤ ± 0.1%
Nominal Power Supply : 4-20mA and 0-5V : 12-24Vdc; 0-10V : 15-24Vdc
Max. Power Supply: 28Vdc
Max. Absorption:
a) 3 wires: 30mA
b) 2 wires: 20mA
Loading Resistance::
a) tension: min. 3KΩ
b) current: from 0 to 470Ω
Insulation Resistance: >2 GΩ
Zero Balance: ± 10% ADJ.
Response Frequency: from 0.5 to 5 kHz
Limit Mechanical Values::
a) service pressure: 100%
b) max. permissible pressure: 150%
c) breaking pressure: >300%
d) highly dynamic pressure: 75%
Reference Temperature: +23°C
Working Temperature Range: -10/+70°C
Process Coupling: 1/4"Gas (*1/2"Gas) Maschio / BSP Male
Tightening Wrench: 27 mm
Tightening Torque: 28 Nm
Protection Class (En 60529): IP65
Sensor Execution Material: INOX 17-4 PH
Electrical Connection: Connector DIN 43650; A/ISO 4400
