AEP Transducers MICROTOR Rotating Torque Transducer (IP40; 10 Nm)

Nominal Torque : 10 Nm

Linearity And Hysteresis : ≤ ± 0.20 %

Temperature Effect (1°C)::

a) on zero: ≤ ± 0.02%

b) on sensitivity: ≤ ± 0.02%

Nominal Sensitivity: 2mV/V

Sensivity Tolerance: ≤ ± 0.2%

Nominal Power Supply: 1-15V

Max. Power Supply: 18V

Input Resistance: 430 ± 20Ω

Output Resistance: 350 ± 5Ω

Insulation Resistance: >2 GΩ

Zero Balance: ≤ ± 0.5%

Limit Mechanical Values:

a) service torque: 100%

b) max. permissible torque: 150%

c) breaking torque: >300%

d) highly dynamic torque: 70%

c) nominal speed: 4000 rpm

Reference Temperature: +23°C

Working Temperature Range: -10/+70°C

Storage Temperature Range: -20/+80°C

Protection Class (En60529): IP40

Sensor Execution Material: Stainless Steel

Case Execution Material: Aluminium

Electrical Connection: Cable 3m

Process Coupling: ●(hexagonal); Quick action chuck
