Accuracy Class According ISO 376 : 1 (from 10% to 100% F.S.)
Accuracy : ≤ ± 0.05 % F.S.
Nominal Load: 1000 kg
Measurement Units : Kg – t – lb – kN – daN - N
Service Temperature: 0 … +50 °C
Storage Temperature: 0 … +60 °C
Relative Humidity: < 90 % not condensed
Temperature Effect (1°C):
a) on zero: ≤ ± 0.015%
b) on sensitivity: ≤ ± 0.005%
Internal Resolution: 16 bit
Reading Per Second: 10 (100ms)
Lcd Display Backlight: Custom 7 segment
Character Hight: 13 mm
Resolution: 1, 2, 5, 10
Digital Filter Function: from 0 to 5
Zero Function: 100 % F.S.
Peak Function: Compression / Tension
Menu Lock Funzion (Loc): Programming protection
Comunication Port: USB 2.0
Type Of Transmission: On Request Or Continue
Transmission Of Measures: max. 10 data per second
Maximum Distance: 5 m
Power Supply: Rechargeable Battery Li-Ion 3.6V 1800Ma/H
Autonomy: 50 hours (continuous operation)
Battery Recharge: From USB port (5Vdc)
Mechanical Limit Values::
a) service load: 100% F.S.
b) max permissible load: 150% F.S.
c) breaking load: >300% F.S.
d) max permissible dynamic load: 75% F.S.
Protection Class (En 60529): IP40
Case: Aluminum
Sensor: Stainless Steel
Weight: ~ 1.5 kg
