Advantech PSD-A40W24 DIN-Rail Power Supply (24VDC; 22VDC ~ 27VDC)

Output Voltage: 24VDC

Output Voltage Adjustment Range: 22VDC to 27VDC

Rated Current: 1.67A

Peak Current (Max Output Current, 3 seconds): 2.50A

Efficiency (typ.): 89%

Output Power: 40 Watts

Input Voltage: 85 ~ 264 VAC; 110 ~ 375 VDC

OVP ( Over Voltage Protection): 35V max (Latch Mode)

OCP (Output Peak Current Protection, 3~5 sec): 2.50A

Operating Temperature: -25 ~ 70°C (Please Refer to Power Derating Curve)

Power Derating: Full load to 60°C; output power derated 2.5% per °C

Operating Humidity: 5 ~ 95% RH, non-condensing

Storage Temperature: -40 ~ 85 °C
