Advantech IPS-X64A1K2W-A Power Supplies A/D 100-240V 1200W PS2 ATX 80+PLATINUM

Width: 150 mm

Height: 86 mm

Length: 160 mm

Dimensions: 160 mm x 150 mm x 86 mm

Output Power: 1.2 kW

Input Voltage: 100 VAC to 240 VAC

Mounting Style: Rack

Input Frequency: 47 Hz to 63 Hz

Load Regulation: Regulated

Number of Outputs: 5 Output

Output Current-Channel 1: 300 mA

Output Current-Channel 2: 3 A

Output Current-Channel 3: 20 A

Output Current-Channel 4: 100 A

Output Voltage-Channel 1: - 12 V

Output Voltage-Channel 2: 3.3 V

Output Voltage-Channel 3: 12 V

Output Voltage-Channel 4: 5 V

Maximum Operating Temperature: + 50 C

Minimum Operating Temperature: 0 C
