Advantech IPS-D22A60W48V-A DIN-Rail Power Supply (60W, 85 ~ 264Vac; 100 ~ 375Vdc)

Output Power : 60W

Input Power: AC to DC

Input Current (maximum): 115V @ 1.8A; 230V @ 1.0A

Input Voltage: 85 ~ 264Vac; 100 ~ 375Vdc

Input Frequency: 47 ~ 63 Hz

Efficiency: 88% @ 230Vac

Main Connector: Screw Terminal

Operating Temperature: -20 ~ 70°C

Power Derating: Full load to 50°C, Derate 2% per °C

Storage Temperature: -40 ~ 85°C

Storage Humidity: 5 ~ 95% RH

Output Rating: 48V @ 1.25A

MTBF (hours @ 25°C): 500K

Dimensions (W x H x D): 37.9 x 100 x 94.1 mm

Safety: CE / UL / CB / CCC / TUV / UKCA

Air Cooling: Conventional

LED: Green, DC OK

Mounting Rail: TS35
