Advantech ARK-1220L Fanless Embedded Box PCs (Intel Atom E3940 Quad Core SoC)

Processor: Intel Atom E3940 Quad Core SoC (1.6 GHz, turbo boost up to 1.8 GHz)

RAM: DDR3L 1600 MHz, up to 8GB

Storage: Supports SATA III 2.5 inch HDD and mSATA

Graphics: Intel HD Graphics 500, supports dual 4K display (HDMI1/HDMI2: 3840x2160 @30Hz)

I/O Ports: 4 x USB 3.0, 2 x LAN (Intel i210 GbE), 2 x RS-232/422/485

Power Supply: Wide input range from 12V ~ 28V DC

Operating Temperature: -30°C to 70°C with airflow of 0.7 m/s

Dimensions: 53.5 x 158 x 114 mm

Weight: 0.9 kg

Humidity: 95% @ 40°C (non-condensing)

Certifications: CE/FCC, CCC, BSMI
