Media: Air.
Generated Pressure Range: 95% vacuum to 1,000 psi (70 bar) positive pressure.
Adjustment Resolution: 10 Pa (0.1 mbar)
Material:
Ram/adapters: SS
Body: SS, aluminum
Seals: Buna-N, PTFE, Copper Alloy
Piston volume: 27 ml
Connection
Hand-tight connectors for both test gauge and reference
gauge.
1/4NPT female, 1/2NPT female, 1/4BSP female, 1/2BSP female, or M20X1.5 female
Dimensions:
Height: 5.5" (140 mm)
Base: 12.4" (315 mm) x 7.8" (198 mm)
Weight: 5.7 lb (2.6 kg).
Accessories included
O-ring: 20 pcs
Manual: 1 pc
Carrying case (917-X-SET models only)
