Media: Mineral oil or Deionized water
Reservoir capacity: 420 ml
Pressure Range: 85% vacuum to 15,000 psi (1,000 bar) positive
Material:
Ram/adapters: SS
Body: SS, aluminum,Copper
Seals: Buna-N
Connection
Hand-tight connectors for both test gauge and reference gauge.
1/4NPT female, 1/2NPT female, 1/4BSP female, 1/2BSP female, or M20X1.5 female
Dimensions:
Height: 6.9" (175 mm)
Base: 17.9" (455 mm) x 15.0" (380 mm)
Weight: 28.7 lb (13 kg).
Piston Volume:1.5ml
Accessories included
Mineral oil,1 bottle (250 ml)
O-ring: 20 pcs
Manual: 1 pc
Carrying case (946-X-SET models only)
